Range Rover Evoque: Front Seat Recliner Motor
Removal
NOTE: Removal steps in this procedure may contain installation details.
All vehicles
1. Refer to: Specifications (414-01 Battery, Mounting and Cables, Specifications).
2. Refer to: Standard Workshop Practices (100-00 General Information, Description and Operation).
3. Refer to: Front Seat Control Switch (501-10 Seating, Removal and Installation).
4. Refer to: Front Seat (501-10 Seating, Removal and Installation).
5. NOTE: If equipped.
6.
7.
8.
9.
10.
- If equipped.
11.
12.
3-door
13. NOTE: Using suitable tools remove the front seat release lever.
All vehicles
14.
15.
16.
17. WARNING: The SRS electrical connectors are unique. DO NOT force, or attempt to connect electrical connectors to the wrong sockets.
18. WARNING: Make sure that the air bag is correctly installed in to the fabric chute. Failure to follow this instruction may result in incorrect operation of the air bag.
Torque: 7 Nm
19.
20.
Vehicles with heated front seats
21.
22.
All vehicles
23.
24. NOTE: Repeat the procedure for the other side.
25.
26.
3-door
27.
28.
29.
30. NOTE: Repeat the procedure for the other side.
31.
All vehicles
32.
33.
34.
35.
36.
37.
38.
39.
40. Torque: 28 Nm
Installation
1. To install, reverse the removal procedure.
